Blue Sea 285 Panel Mount Circuit Breaker 150A (Bulk)

Provides medium duty circuit protection for 150 Amp loads when switching and circuit protection are both required. - Trip-free - cannot be held closed after trip - Visible reset lever shows open condition - Drop-in replacement for 185-Series Circuit Breakers Regulatory: - CE marked - Meets SAE J1171 external ignition protection requirements, †AIC ratings achieved using SAE J1625 - IP67 - protected against immersion up to 1 meter for 30 minutes Specifications: Interrupting Capacity: 3000A at 48V DC Vmxo: 48V DC Operating Temperature: -40 C min to +85 C max Type: Thermally Responsive Bi-Metal Blade Class: Type III Switchable/Manual Reset - Trip Free Terminal Stud: M6 Terminal Stud torque: 50 in-lb Mounting: 1/4" Screw
