Blue Sea Battery Switch M Series 3 Position Selector Red

Blue Sea M-Series battery selector switch 6008 with 3 positions in red. The battery switch isolates battery banks to all loads or combines battery banks to all loads. Switch Type: Selector Colour: Red Switch Positions: 3 Battery Combine: No Alternator Field Disconnect: No Maximum Voltage: 32V DC Stud Size: 3/8" Terminal Stud Torque: 120 in-lb (13.56 Nm) Continuous Rating: 300A Intermittent Rating: 500A (5 Min) Cranking Rating 30 sec: 900A Battery Inputs: 2 Cable Clearance For 4/0 AWG Cables: 28.45mm (1.12") Mounting Holes: Accept #10 Screw Stud Material: Tinned Copper Stud Torque: 120 in-lb (13.56 Nm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 0.35 kg (0.77lb) Approvals: CE, IP66, ISO 8846, UL 1107 & UL 1500
