Blue Sea MRBF Fuse Block 3 Independent Sources

MRBF - Marine Rated Battery Fuse Surface mount fuse blocks accommodate three MRBF fuses for consolidated high amperage circuit protection The independent source fuse block (8-25194) is ideal for 3 output battery chargers The common source fuse block (8-25196) provides 3 loads from a single source Clip-on cover insulates terminal connections Versatile wiring options allow all wires to come out a single side Label recesses for easy circuit identification One-piece stainless flange nuts ensure safe and secure connections Ignition protected when used with MRBF fuses Fuses sold separately (see page 553 of the Aquafax main catalogue) Regulatory Meets ISO 8846 and SAE J1171 external ignition protection requirements when used with MRBF fuses and cover is securely latched Specifications: 8-25194 8-25196 Voltage Max. Operating: 58V DC 58V DC Amps Max. Operating: 300 per block 300 per block (using 4/0 cables) - 240A per circuit Terminal Fuses available: 30A-300A 30A-300A Terminal Stud Size: 5/16" -18 (8mm) 5/16" -18 (8mm) Mounting Hole Size: #10 (5mm) #10 (5mm)
