T85 ROTARY STEERING SYSTEM
Features & Technical Specifications
All stainless steel cable output ends.
Corrosion resistant materials.
Particularly suitable where clearance is limited.
Lock-to-lock steering wheel turns: approximately 3
Stroke 228mm (9").
Maximum allowable steering wheel diameter: 406mm (16").
Minimum steering cable bend radius: 200mm (7.9")
Minimal feedback.
Compact for mounting.
T85 steering system should not be used on boats equipped with engines that
exceed the maximum horsepower rating of the boat.
Exceeds EN28848 and ABYC P17 safety standards.
